About this product
| 12V Power Outlet | Dual USB-C | ||
| Input Voltage (12V System) |
10-15V DC | Input Voltage (12/24V System) |
10-15V DC |
| Input Current Max | 15A | Input Current Max | 15A |
| Output Max | 225W | Output Type C (12V System) |
5V⎓3A, 9V⎓3A, 12V⎓3A Max |
| Standby Draw | 0.01W | Output Type C (24V System) |
5V⎓3A, 9V⎓3A, 12V⎓3A, 20V⎓3A Max |
| ⚠ 15A/225W: 30 Mins Max | Standby Power Draw | 0.01W | |
| Anderson 50A DC Connection | SAT Connection | ||
| Connection Type | Anderson SB50 – Grey | Connection Type | Dual F-Type Coaxial |
| Compatible Connector | Anderson SB50 – Black, Grey | Dual F-Type Coaxial | Nickel-Plated Brass |
| Connector Max Current | Rated 50A (6AWG cable) | Impedance | 75Ω |
| Connector Max Voltage | Rated 600V DC | Applications | Satellite & TV Systems |
| Max Power Delivery (12V System) |
600W | ||
| Max Power Delivery (24V System) |
1200W | ||
| Max Power Delivery (48V System) |
2400W | ||
| SB50 terminal crimps are notincluded. Only genuine Anderson Power connectors and terminal crimps should be used with this product and are available from Anderson Power.
Sizes available:
|
|||
| Product Approvals | |
| Waterproof Rating | IP68, IP69K Front only when lid closed |
| Cerfications | CE, FCC, C-Tick, ROHS, WEEE |
Drilling Template: (CLICK HERE)
Installation Instructions: (CLICK HERE)
Technical Drawing: (CLICK HERE)
